Circular Saw Machines
P-100 High-Speed CNC Circular Saw Machine
The P-100 is a CNC circular saw for production cutting of metal bars, tubes, and profiles, including round pipes from Ø20 to Ø100 mm. Its AC servo-driven straight feed and hydraulic clamping support controlled cutting, while the fixed-length feeding system helps position material for repeated cuts. A stable feeding rack, high-torque gear transmission, and Mitsubishi controls support daily operation.
Specifications
- Bar cutting capacity
- Ø20–100 mm
- Angle steel cutting range
- 20–85 mm
- Round pipe cutting capacity
- Ø20–100 mm
- Square pipe cutting range
- 20–85 mm
- TCT saw blade
- Ø360×2.6t mm
- Spindle speed
- 30–160 rpm, stepless speed regulation
- Spindle drive motor
- 11 kW, 6-pole variable-frequency motor
- Cut-off length
- 8–99 mm
- Minimum remnant length
- 80 mm
- GFC feed length
- 6–800 mm (single stroke) / 9999 mm (multiple strokes)
- Material length
- 2000–6000 mm
- Feeding rack length
- 1200 mm
Product Features
- Stable Feeding Rack
Equipped with a sturdy feeding rack to provide stable and reliable material support during the cutting process.
- High-Torque Gear Transmission
The high-torque gear transmission system provides strong and stable power transmission for efficient metal cutting.
- Reliable Imported Electrical Components
Selected imported electrical components provide reliable machine control and stable operation for demanding industrial applications.
- High-Quality NSK Bearings
High-quality NSK bearings are used to ensure smooth operation, reduce mechanical wear, and enhance overall machine durability.
- Straight-Feed Cutting & Durable Construction
The straight-feed cutting design provides stable material movement and consistent cutting performance. The robust machine construction is designed for long-term, reliable operation.
- Reliable Mitsubishi Control System
The Mitsubishi control system offers intuitive and user-friendly operation, making machine settings and daily operation easier for operators.
